Audio Collector AI2

Ai2 is a dual channel USB audio analysis collector with analog 2-channel input/output, using a 6.35mm audio socket and TYPE-B communication interface, supporting multiple sampling rate adjustments (44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz), and equipped with ABTEC Flex Key analyzer, it can complete comprehensive testing of audio product electroacoustic indicators.
  • Features
  • Specification
  • Options and upgrades
  • Resource centre
    • Commodity name: Audio Collector AI2
    • Commodity ID: AI2

    Ai2 is a dual channel USB audio analysis collector with analog 2-channel input/output, using a 6.35mm audio socket and TYPE-B communication interface, supporting multiple sampling rate adjustments (44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz), and equipped with ABTEC Flex Key analyzer, it can complete comprehensive testing of audio product electroacoustic indicators.

    Ai2 is a dual channel USB audio analysis collector with analog 2-channel input/output, using a 6.35mm audio socket and TYPE-B communication interface, supporting multiple sampling rate adjustments (44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz), and equipped with ABTEC Flex Key analyzer, it can complete comprehensive testing of audio product electroacoustic indicators.

    • Technical Specifications

                              Item                                               output characteristic                                  Input characteristics

      Number of output/input channels                                 2                                                                 2

      Type of output/input port                         6.35mmBalanced audio socket                 6.35mmBalanced audio socket

      Maximum output/input voltage                                 2Vrms                                                         2Vrms

      Frequency response                                         ±0.2dB(20Hz-90kHz)                                 ±0.2dB(20Hz-40kHz)

      THD+N                                                                      < -103dB                                                   < -103dB

      Signal to Noise Ratio                                                > 103dB                                                     > 103dB

      Digital Noise Floor                                                   < -100dB                                                    < -100dB

      Crossfire                                                                   < -100dB                                                    < -100dB

      Flatness                                                                         ±1dB                                                         ±1dB

    • General Indicators

      Size(W*D*H):150mm*150mm*45mm

      Weight:1.0kg±0.1kg

      Working voltage:DC 5V/3A

      Communication port type:TYPE_B

      Sampling rate:support 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz,192kHz
